PR 5220 Instrument Manual Commissioning
Sartorius EN-83
4.6 Calibrating Digital Load Cells Type ‘Pendeo®’
4.6.1 General Information
The digital load cells have been calibrated at the factory based on the acceleration of gravity Hamburg,
Germany: 9.81379 m/s². The calibration data in the load cells are invariable. The calibration data for the
gravity acceleration at the place of installation can be adapted only in the instrument and protected against
overwriting (see Chapter 4.1.1). With applications for use in legal metrology, the legal requirements and the
conditions given on the test/approval certificate must be taken into account when selecting the settings.
For connecting digital load cells (xBPI load cells) a Firmware from 2.10 onwards is required.
4.6.2 Viewing the Interfaces
The existing interfaces can be viewed under -[Show HW-slots]:
Info/HW-Slots
Builtin
RS485
Built-in interface
Builtin
analog out
Built-in interface
Builtin
digital I/O
Slot 4
PR5220/01
Profibus-DP
4.6.3 Selecting and Setting up the Interface
Select -[Serial ports parameter]-[xBPI-Port] to choose a serial interface.
Setup/Serial ports
Remote display
-none-
SMA
-none-
xBPI-Port
Builtin RS485
Press to select RS-485.
Press [Param].
Param
The menu appears.
Setup/Serial ports/Slot2 RS485
Assigned to
xBPI-Port
Protocol
xBPI
Baudrate
19200 bd
Press
to select the value ‚19200 bd‘.
Bits
8
Parity
odd
Stopbits 1
Press
to select the value ‚1‘.
