Commissioning
PR 5220 Instrument Manual
EN-96 Sartorius
4.7 Configuring General Parameters
The configuration of parameters which are not related to the weighing electronics is divided into several
sections (see Chapter 4.3.8).
4.7.1 Serial Interfaces [Serial ports parameter]
To configure the serial interfaces, select -[Serial ports parameter].
Select [Serial ports parameter] with
Operating parameter
and
Remote display
Builtin RS485
Param
Config
Remote display protocol [Remote display]
Select the serial interface to which the remote display is connected and then select [Param] to define the
[Baudrate] and the remote display type [Mode] connected.
Setup/Serial ports/Builtin RS485
Baudrate
9600 bd
Select [Baud rate] with
Bits 7
and set the baud rate with
.
Mode multiple transmitters
Several remote displays are connected.
Device ID A
Address of the instrument
Next Device ID B
Next address of the instrument
You can only set the baud rate to 300, 600, 1200, 2400, 4800 or 9600. The other parameters (displayed in
light-gray) cannot be changed.
If only 1 instrument is connected to a remote display (normal case), [Mode] must be set to [single transmitter].
If more than 1 instrument is connected to 1 remote display, [Mode] must be set to [multiple transmitters].
At [Device Id] the own instrument address (A, B, C ...) has to be entered, at [Next Device Id] the address of the
subsequent instrument has to be entered
Press
to return to the menu ‚Serial ports’.
