4.9 Digital Outputs and Inputs
4.9.1 Configuring Digital Outputs
Configure the required function for [Output 1] to [Output 3] by selecting a signal from the list. The output goes
to the corresponding state, see Example.
Press
and select [Digital I/O parameter] to open the configuration menu.
Setup/Digital I/O parameter
[Output 1] is true (active), when the weight value drops below zero (X35=1).
[Output 2] remains (active), as long as the weight is not above Max (X33=0).
[Output 3] is true (active), when the weight is zero ±¼ d (X36=1).
Selection list for output functions
Function SPM bit Description
actual diginp1 X00=0 Digital input 1: not active
actual diginp2 X01=0 Digital input 2: not active
actual diginp3 X02=0 Digital input 3: not active
actual limit 1 X16=0 Limit signal 1: not active
actual limit 2 X17=0 Limit signal 2: not active
actual limit 3 X18=0 Limit signal 3: not active
ADC error X32=0 General error in the weighing point: not active (no error)
above Max X33=0 Weight above Max: not active
overload X34=0 Weight above Max plus the ‘overload’ value: not active
below zero X35=0 Weight not below zero
center zero X36=0 Weight not within ¼ d of zero
inside ZSR X37=0 Weight not within zero-setting range
standstill X38=0 No mechanical stability of the scale
out X39=0 Weight not below zero or above Max
command error X48=0 For internal use only.
command busy X49=0 For internal use only.
power fail X50=0 Set after power-on (=power failure): not active
test active X56=0 Analog test was not started.
cal active X57=0 For internal use only.
tare active X58=0 Instrument is not tared.
marker bit 1 X64=0 Marker bit 1 not set, after power-on the markers are set to ‘0’.
marker bit 2 X65=0 Marker bit 2 not set, after power-on the markers are set to ‘0’.
marker bit 3 X66=0 Marker bit 3 not set, after power-on the markers are set to ‘0’.
