Commissioning
PR 5220 Instrument Manual
EN-110 Sartorius
4.10 Analog Output
Determine the analog output under -[Analog output parameter].
Setup
Serial ports parameter
Operating parameter
Fieldbus parameter
Network parameter
Weighingpoint
Limit parameter
Digital i/o parameter
Analog output parameter
Press
and
to select [Analog output parameter]
Setup/Analog output parameter
Analog mode
no output
Analog range 0 ... 20 mA
Output on error 0 mA
Output if > Max 20 mA
Weight at 0/4 mA 0 kg
Weight at 20 mA 3000 kg
[Analog mode]
[no output] The analog output is not used
[Gross D08] Output of the gross weight
[Net D09] Output of the net weight
[Select D11] Output of the value on the display
[Transparent D30] Output of the value in D30
[Analog range]
[0...20 mA] Output of 0... 20 mA
[4...20 mA] Output of 4... 20 mA
[Output on error]
[0 mA] Set the output to 0 mA
[4 mA] Set the output to 4 mA
[20 mA] Set the output to 20 mA
[hold] The last output value is held
[Output if < 0]
[0 mA] Set the output to 0 mA
[4 mA] Set the output to 4 mA
[20 mA] Set the output to 20 mA
[linear] The output drops below 4 mA up to the limitation (at 4 .. 20 mA)
[Output if > Max]
[0 mA] Set the output to 0 mA
[4 mA] Set the output to 4 mA
[20 mA] Set the output to 20 mA
[linear] The output exceeds 20 mA up to the limitation
[Weight at 0/4 mA]
Weight value for 0/4 mA output
[Weight at 20 mA]
Weight value for 20 mA output
Press
to return to the previous menu.
