Sartorius PR 5220 Series User Manual

PR 5220 Instrument Manual Commissioning
Sartorius EN-49
4.3.8 Setup Menu
- Serial ports parameter
- Remote display
<none>, Builtin RS485
- Param
Assigned to, Protocol, Baudrate., Bits, Parity, Stopbits, Mode
- SMA
not used <none>, Builtin RS485
- Param
Assigned to, Protocol, Baudrate., Bits, Parity, Stopbits,
- xBPI-Port
<none>, Builtin RS485
- Param
Assigned to, Baudrate, Bits, Parity, Stopbits
- Operating parameter
- AccessCode
Access code for changes
- SetTareKey
Tare&reset tare, tare&tare again, disabled
- SetZeroKey
Only when not tared, reset tare on zeroset , disabled.
- Fieldbus parameter
Only for PR 5220/01, ../04, ../06 und ../07, see Chapter 4.7.3
- Network parameter
Hardware address (read only), Hostname (instrument name), Use DHCP,
IP address (read only), Subnet mask (read only), Standard gateway (read only),
Remote access, VNC-Client (access restriction)
- Weighingpoint
<Internal A>, xBPI-Scale
- Calib
‚Internal A’ selected: New, Modify, Param, see Chapter 4.3.8.1
- Setup
‚xBPI-Scale’ selected: Calibration, Configuration, Select, Show device info,
see Chapter 4.3.8.2
- Config
‚xBPI-Scale’ selected: Type, W&M, Tare timeout, Serial number, SBN Address,
see Chapter 4.3.8.2
- Param
‚xBPI-Scale’ selected: Assigned to, Baudrate, Bits, Parity, Stopbits,
see Chapter 4.3.8.2
-Limit parameter
- Limit 1/2/3 on/off
Limit 1/2/3 'on'/ 'off', Action, Condition; see Chapter 4.8
-Digital I/O parameter
- Output 1/2/3
Configuring outputs; see Chapter 4.9.1
- Limit 1/2/3 on/off
Inputs, Action, Condition; see Chapter 4.9.2
- Analog output parameter
- Analog mode
Analog output parameter: Gross D08, Net if tared D09, Selected D11,
Transparent D30, no output, see Chapter 4.10
- Analog range
0…20 mA, <4…20 mA>
- Output on error
Output on error: 0 mA = set to 0 mA, <4 mA> = set to 4 mA, mA = set to 20
mA, hold = last output value remains unchanged
- Output if <0
Output if <0: set 0 mA = 0 mA, set <4 mA> = 4 mA,
set 20 mA = 20 mA, linear = goes below 4 mA down to the limit (with 4…20 mA)
- Output if >Max
set 0 mA = 0 mA, set 4 mA = 4 mA,
set <20> mA = 20 mA, linear = goes above 20 mA up to the limit
- Weight at 0/4 mA
Weight value for 0/4 mA output
- Weight at 20 mA
Weight value for 20 mA output
