SLT12 User Manual
100
9.3
Calculator
Tool for performing simple mathematical calculations.
9.4
Calc. XYZ
The coordinate orthogonal calculation function can derive the specific coordinate information of the endpoint by
setting the spatial relationship between the start point and the endpoint relative to the start point.
The starting point can be input and selected by manual input, list selection, measurement selection, etc. After
selecting the starting point, set the starting azimuth, rotation angle, flat distance, and elevation difference
information of the ending point relative to the starting point, click the "Calculate" button, and then display the
calculation result of the coordinates of the ending point after projection.
Click on the "Graph" button to view the relationship between the start and end points of the plane.
Figure 9- 14
