SLT12 User Manual
101
Figure 9- 15
Figure 9- 16
9.5
Inverse
The coordinate back-calculation function can derive the spatial information of the endpoint concerning the start
point from the coordinate information of the start point and the endpoint.
The start point and end point can be input and selected by manual input, list selection, measurement selection,
etc. After selecting the start point and end point, click the "Calculate" button, and the SD (spatial linear distance
between the start point and the end point), HD (horizontal linear distance between the start point and the end
point), VD (elevation difference between the start point and the end point), azimuth and slope information of the
endpoint relative to the start point will be displayed after calculation. (horizontal distance between the start point
and end point), VD (elevation difference between the start point and end point), azimuth, and slope information.
Click on the "Graph" button to view the relationship between the start and end points of the plane.
