SLT12 User Manual
9
HL
Horizontal angle (left angle)
HD
Horizontal distance. dHD is to stake out differences in horizontal distance
VD
Elevation difference. dVD is to stake out differences in elevation
SD
Slope distance. dSD is to stake out differences between slope distances
N
North coordinates, dN is to stake out differences between north-coordinates
E
Eastern coordinates, dE is to stake out differences between East-coordinates
Z
Elevation coordinates, dZ is to stake out differences between Z-coordinates
m
Unit in meters (metric units)
ft
Units in feet (imperial)
fi
In feet and inches, feet before the decimal point and hundredths of an inch after the
decimal point
X
The value along the baseline direction in point projection measurement, the direction from
the starting point to the endpoint is positive
Y
Point projection measurement of values in the direction of vertical deviation from the
baseline
Z
Elevation of the target in point projection measurement
