SATO E series User Manual

Appendix C: Custom Characters and Graphics
SATO Programming Reference Page C - 5
3. Transfer the image into a bit map representation and then into hexadecimal for-
mat:
4. Using the hexadecimal data, send the following code to print the graphic image as
designed.
<ESC>A<ESC>H0100<ESC>V0100<ESC>GH006006
FFFFFF FFFFFF FFFFFF FFFFFF C00000 000003
C00000 000003 C000FF FFFFF3 C00080 000013
C00080 000013 C0009F FFFF13 C00080 000013
C00080 000013 C0009F FFFF13 C00080 000013
C00080 000013 C000FF FFFFF3 C00000 000003
C00000 000003 C00000 000003 C00000 000003
C00000 000003 C00000 000003 C00003 C00003
C00007 E00003 C0000F F00003 C0000F F00003
C0000F F00003 C0000F F00003 C00007 E00003
C00003 C00003 C00000 000003 C00000 000003
C00000 000003 C00000 000003 C00001 800003
C00003 C00003 C00003 C00003 C00003 C00003
C00003 C00003 C00003 C00003 C00003 C00003
C00003 C00003 C00003 C00003 C00003 C00003
C00003 C00003 C00001 800003 C00000 000003
C00000 000003 FFFFFF FFFFFF FFFFFF FFFFFF
BIT MAP HEXADECIMAL FORMAT
1 2345 6 123456
11111111 11111111 11111111 11111111 11111111 11111111FF FF FF FF FF FF FF
11111111 11111111 11111111 11111111 11111111 11111111FF FF FF FF FF FF FF
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 11111111 11111111 11111111 11110011C0 00 FF FF FF 03 03
11000000 00000000 10000000 00000000 00000000 00010011C0 00 80 00 00 13 13
11000000 00000000 10000000 00000000 00000000 00010011C0 00 80 00 00 13 13
11000000 00000000 10011111 11111111 11111111 00010011C0 00 9F FF FF 13 13
11000000 00000000 10000000 00000000 00000000 00010011C0 00 80 00 00 13 13
11000000 00000000 10000000 00000000 00000000 00010011C0 00 80 00 00 03 03
11000000 00000000 10011111 11111111 11111111 00010011C0 00 9F FF FF 13 13
11000000 00000000 10000000 00000000 00000000 00010011C0 00 80 00 00 13 13
11000000 00000000 10000000 00000000 00000000 00010011C0 00 80 00 00 13 13
11000000 00000000 11111111 11111111 11111111 11110011C0 00 FF FF FF F3 F3
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 13 13
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 13 13
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 13 13
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 13 13
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000111 11100000 00000000 00000011C0 00 07 E0 00 03 03
11000000 00000000 00001111 11110000 00000000 00000011C0 00 0F F0 00 03 03
11000000 00000000 00001111 11110000 00000000 00000011C0 00 0F F0 00 03 03
11000000 00000000 00001111 11110000 00000000 00000011C0 00 0F F0 00 03 03
11000000 00000000 00001111 11110000 00000000 00000011C0 00 0F F0 00 03 03
11000000 00000000 00000111 11100000 00000000 00000011C0 00 07 E0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 00 00 00 03 03
11000000 00000000 00000001 10000000 00000000 00000011C0 00 01 80 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000011 11000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000001 10000000 00000000 00000011C0 00 01 80 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 03 C0 00 03 03
11000000 00000000 00000000 00000000 00000000 00000011C0 00 03 C0 00 03 03
11111111 11111111 11111111 11111111 11111111 11111111FF FF FF FF FF FF FF
11111111 11111111 11111111 11111111 11111111 11111111FF FF FF FF FF FF FF

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
