12) V10 bypass Actuation of the bypass valve.
ON:
The valve opens and water flows.
OFF:
The valve is closed and there is no
flow.
On/off Water is output at the be-
verage outlet.
Only with the appropriate
machine equipment and
activated system parame-
ter.
13) V13+M7 air pump Actuation of the air pump and valve.
ON:
The air pump runs, valve V13 opens.
OFF:
The pump is idling, the valve is
closed.
On/off -
14) heater booster (*) Actuation of the heater booster.
ON:
The heating is switched on.
OFF:
The heating is switched off.
On/off (*) The marked parame-
ters are automatically swit-
ched off by the machine
control to protect the com-
ponents.
15) M1 grinder left Actuation of the left grinder motor.
ON:
The left grinder is switched on.
OFF:
The left grinder is switched off.
On/off Before starting the grinder,
mount the bean hopper.
16) M2 grinder right Actuation of the right grinder motor.
ON:
The right grinder is switched on.
OFF:
The right grinder is switched off.
On/off Before starting the grinder,
mount the bean hopper.
17) M3 brewer motor down (*) Downward actuation of the brewer motor.
ON:
The brewing unit moves downward
slightly.
OFF:
The brewer motor remains switched
off.
On/off (*) The marked parame-
ters are automatically swit-
ched off by the machine
control to protect the com-
ponents.
The brewing unit must be
manually returned to its
basic position. Check this
in the "Move brew cylin-
der" menu.
18) M3 motor brewer up (*) Upward actuation of the brewer motor.
ON:
The brewing unit moves upward
slightly.
OFF:
The brewer motor remains switched
off.
On/off (*) The marked parame-
ters are automatically swit-
ched off by the machine
control to protect the com-
ponents.
The brewing unit must be
manually returned to its
basic position. Check this
in the "Move brew cylin-
der" menu.
Parameters: Output test
Display text Description Setting range Notes
