SET.14 of 16 SEL-749M Settings Sheets

SET P F, SET P 3, or SET P 4 Commands

SEL-749M Relay Instruction Manual Date Code 20080918

Date _______________

Group______________

NOTE: Port 4 has the following additional settings when DeviceNet card is used. These settings can be viewed by using either the STA serial port

command or the front-panel menu item

Status. The settings can be changed only at the rear of the relay on the DeviceNet card.

MAC_ID (0–63) MAC_ID := _____________________

ASA (8 hex characters assigned by factory) ASA := _____________________

DN_Rate (125, 250, 500 kbps, Auto) DN_Rate := _____________________
