Part IV Display and Control Options
This chapter describes the display modes and control options that are supported by the
Receiver.
4.1 VGA Use Case
ScreenBeam 960 provides built-in VGA input and output ports for compatibility with legacy
devices. The VGA ports follow the rules listed below:
When ScreenBeam is powered on,
 If only HDMI Out is connected, HDMI Out will display video from ScreenBeam;
 If only VGA Out is connected, VGA Out will display video from ScreenBeam;
 If VGA In and HDMI Out are connected, HDMI Out will display video from ScreenBeam;
 If VGA In and VGA Out are connected, HDMI Out will display nothing, and VGA Out will
display video from VGA In;
 If VGA In, VGA Out, and HDMI Out are connected, HDMI Out will display video from
ScreenBeam and VGA Out will display video from VGA In.
When ScreenBeam is powered off,
 HDMI Out will display nothing;
 If VGA In and VGA Out are connected, VGA Out will display video from VGA In.
4.2 Display Mode
The Receiver supports three display modes when connected with a compatible wireless
display application.
In Windows, press the Windows logo + P keys simultaneously ( + P) to launch the
display options and select the desired display mode from the options.
