Manual – MOVIDRIVE® MDX61B Safety Module Option MOVISAFE® DCS..B
105
9
Error and alarm messages
Diagnostics
9.2 Error and alarm messages
The DCS..B option basically distinguishes between three types of messages according
to the following assignment:
Signal Description Impact on the
system
Reset condition
DCS21B DCS31B
Fatal error The last active process is the
operation of the 7-segment dis-
play via system A. System B is in
stop mode.
1)
All outputs are
disabled
The option is passi-
vated by
PROFIsafe
®
.
Input signals are no
longer transmitted
and are set to logic
"0" in the PLC.
Switching the DCS..B option off
and on again
Alarm See "ALARM" operating state in
the table "Indication of the oper-
ating state"
By re-integration
via PROFIsafe
By parameter-
izable input.
ECS When using the ECS function
block in the programming inter-
face, encoder alarm messages
will be identified with "E" instead
of "A".
1)
1) Error detection in system A (odd-numbered) and system B (even-numbered).
The ECS function
block returns "0" as
result.
Drive base: reset
via PROFIsafe
INFORMATION
You can read the corresponding subcode of the error or alarm message of option
DCS..B as follows:
• with MOVITOOLS
®
MotionStudio via the XT option slot on MOVIDRIVE
®
B
• with the DBG60B keypad (firmware status .13)
• via the X87 parameterization and diagnostic interface with the MOVISAFE
®
Assist/Config. software interface
• with a controller that is connected to the inverter via fieldbus. The parameter
channel in PROFIBUS/PROFINET is necessary to read the subcodes of the error
messages.
