106
Manual – MOVIDRIVE® MDX61B Safety Module Option MOVISAFE® DCS..B
9
Error and alarm messages
Diagnostics
9.2.1 List of error messages
INFORMATION
If you receive error messages that are not described here, proceed as follows:
• Under what circumstances did the error occur?
• Save the current configuration set
• Document the error code and the suberror code
• Contact SEW-EURODRIVE Service
Fatal error code F1001, error 108, subcode 001
Error message Configuration data not loaded correctly to option DCS..B.
Cause Connection interrupted while loading the program to the DCS..B option.
Remedy Reload the configuration files. Then switch the DCS..B off and on again.
Fatal error code F1003, error 108, subcode 002
Error message Invalid configuration data for software version of the DCS..B option.
Cause Option DCS..B was configured using a wrong software version.
Remedy Parameterize the DCS..B option with the permitted MOVISAFE
®
software version.
Next, switch DCS..B option off and on again.
Fatal error code F1007, error 108, subcode 003
Error message Unit was programmed with incorrect software interface.
Cause Program or configuration data was loaded into the unit with an incorrect MOVISAFE
®
software.
Remedy Check the DCS..B version and parameterize it again using a valid MOVISAFE
®
soft-
ware. Then switch the DCS..B option off and on again.
Fatal error code F1401/1402, error 108, subcode 019/020
Error message Error while calculating configuration data.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
Fatal error code F1403/1404, error 108, subcode 021/022
Error message CRC of configuration data invalid.
Cause Configuration data have not been uploaded correctly.
Remedy Upload configuration data into unit.
Fatal error code F1405/1406, error 108, subcode 023/024
Error message Error during internal transmission of configuration data.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
