SEW-Eurodrive MOVISAFE DCS21B

Manual – MOVIDRIVE® MDX61B Safety Module Option MOVISAFE® DCS..B
129
10
Plug connectors
Technical Data
10.8.2 Pin assignment X81
Type: Phoenix terminal, 10-pole
10.8.3 Pin assignment X82
Type: Phoenix terminal, 4-pole
10.8.4 Pin assignment X83
Type: Phoenix terminal, 2-pole
X81
PIN
Assign-
ment
Signal description Specification
1 Pulse 1 Pulse output 1 for crossfault monitoring
DC 24 V, pulsed
Clock frequency:
• 214 Hz (DCS21B)
• 240 Hz (DCS31B)
2 DI1 Input 1
DC 20 V to DC 29 V
3 DI2 Input 2
4 DI3 Input 3
5 DI4 Input 4
6 Pulse 2 Pulse output 2 for crossfault monitoring
DC 24 V, pulsed
Clock frequency:
• 214 Hz (DCS21B)
• 240 Hz (DCS31B)
7 DI5 Input 5
DC 20 V to DC 29 V
8 DI6 Input 6
9 DI7 Input 7
10 DI8 Input 8
X82
PIN
Assign-
ment
Signal description Specification
1 DO0_P HISIDE output 0 DC 24 V, 0.25 A
2 DO0_M LOSIDE output 0 DGND
3 DO1_P HISIDE output 1 DC 24 V, 0.25 A
4 DO1_M LOSIDE output 1 DGND
X83
PIN
Assign-
ment
Signal description Specification
1 DO2_P HISIDE output DC 24 V, 1.5 A
2 DO2_M LOSIDE output DGND
