Manual – MOVIDRIVE® MDX61B Safety Module Option MOVISAFE® DCS..B
10
CE marking
Technical Data
10 Technical Data
10.1 CE marking
10.2 General technical data
10.3 General electrical data
The MOVISAFE
®
DCS..B module is a safety component according to annex IV of Ma-
chinery Directive 2006/42/EC. It was developed, designed and produced in compliance
with the above mentioned directive as well as with EMC Directive 2004/108/EC.
MOVISAFE
®
DCS..B
Interference immunity Meets EN 61800-3
Ambient temperature
1)
.
1) Observe the maximum permitted ambient temperature of MOVIDRIVE
®
B
−10 °C to +80 °C
Climate class 3K3 (EN 60721-3-3)
Storage temperature −10 °C to +80 °C
Degree of protection IP00 (EN 60529)
MOVISAFE
®
DCS..B
Supply voltage DC 24 V, −15% / +15%, type PELV, pre-fusing 2 A
Nominal data of digital inputs DC 24 V, 20 mA, type 1 according to EN 61131-2
Nominal data of digital outputs DC 24 V
250 mA (DO0_P/M; DO1_P/M)
1500 mA (DO2_P/M)
Maximum inductive load at DO0_P, DO1_P: 0.5 J
Pulse outputs Max. 100 mA
