Chapter 9 Specifications
Mobile DaRt Operation Manual
9-4
MUX-100D MUX-100DJ
Collimator
R-20C
Shape Rectangular
Max. field
430 × 430 mm SID 1m
Field
Min. field
0 × 0mm (leaves overlapped)
Average illumination > 160 lx
Contrast ratio of edge > 3
Accuracy
2％ of SID
Display of center Cross lines
Type of lamp Halogen lamp (12V, 100W), #55939
Light field
Illuminating period 30 seconds, with automatic turn-off time switch
SID indicated 1, 1.5, 2 m
Dimensions indicated 20(8), 23(9), 25(10), 28(11), 30(12), 36(14), 43(17) cm(in.)
Field size
indication
Accuracy of SID
indication
5%
Drive of leaves
manual
Mounting dimension (Focus to fit surface
distance)
56 mm
External dimension (W × D × H)
202 × 211 × 200 mm
X-ray tube Assembly*
Model Name
0.7U163CS-36
Spot size
0.7mm
Target angle 16deg
Nominal X-ray
tube Voltage
Radiography 125kV
Max. Heat 750kJ(1060kHU)
X-ray tube
Assembly
Max. Continuous heat
dissipation rate
120W(170HU/s)
X-ray Tube
Max. Anode heat
dissipation rate
212kJ(300kHU)
Max. Anode heat
dissipation rate
800W(1130HU/s)
Max. Continuous heat
dissipation rate
210W(300HU/s)
Weight 13kg
Battery
Type Small sized value regulated lead-acid battery
Specification 12V
Quantity 20 pieces
Minimum specific filtration
Total 2.5 mm Al 70 kV
X-ray tube assembly Equivalent to 1.5 mm Al 70 kV
Multi-leaf collimator Equivalent to 1.0 mm Al 70 kV
Classification of the system
Method of protection against electric shock
ClassⅠ (only during charging)
Internal powered (during powered by internal battery)
Degree of protection against electric shock Type-B
Classification according to operation mode Continuous operation with intermittent load
*For detail about X-ray-tube assembly, please refer to X-ray tube operation manual (M535-E219).
