9.1 Specifications
Mobile DaRt Operation Manual
9-5
CXDI-50G
CXDI-50G is containing mainly three componets;
Imaging unit; Digital Cassette that has the mobility and can be used on the optional angles
Power box; Power supply and data gateway for imaging unit mounted in the MUX-100D.
CXDI ; Digital Radiography Operation System for CXDI-50G, installed in Control PC and controled with
Touch panel monitor on the MUX-100D.
Imaging unit
MUX-100D MUX-100D
Effective range 35x 43 cm
Effective Number of Pixels 2208 x2688
Pixel Pitch
160µm x 160µm
Imaging Unit mass 4.8kg (except Grid)
Mechanical strength Load uniformly: 150kg
Load partly: 100kg/
φ
40mm
Maximum irradiation time 1000msec
Mass 4.8 kg (Except cable)
Dimension 491(W) x 477(D) x 23(H)mm with operation grip
Grayscale 12bit (4,096 grayscale)
Option
Grid Snaps onto the Imaging unit. Attenuation equivalent : 2,3mmAl.eq.
For detail about CXDI, please refer to CXDI series operation manual (Canon CXDI Digital Radiography).
Options
MUX-100D MUX-100DJ
Remote controller
Infrared type
Ready operation, X-ray operation, Collimator lamp ON/OFF
Removable X-ray protective screen Removable X-ray protective acrylic screen
Dose Area Meter Dose Area Meter
