SICK DL100 Pro

8024484/2019-06-06 • © SICK AG • Subject to change without notice 27
Mounting
6.3 Selectingandmountingthereector
NOTE!
→ For suitable reectors and reective tape, see
Page 116, Chapter 15.1.
Reectorsize • Selectareectorsizethatallowstheentirelightspottohitthereector
even if there are vibrations.
• Ifthereectorisinstalledontoavehicle,asmallerreectorwilltypically
suce.
Requirements • Reectivesurfacesneartothereectormaycausebeamswitchingor
lightscatterandleadtoincorrectmeasurementsasaresult.Reective
surfacesinclude,forexample,storageproles,palletswithstretchwrap,
or rails.
• If the distance measuring device is mounted in the driving axis of a stor-
ageandretrievalsystem,tiltthereectortowardtheceilingawayfrom
the rail (approx. 1 to 3 degrees). →Seethegurebelow.
• If the distance measuring device is mounted in the lifting axis of a
storageandretrievalsystem,tiltthereectorawayfromthemastsystem
(approx. 1 to 3 degrees). →Seethegurebelow.
S
et
E
s
c
<
<
approx. 1° … 3°




S
et
E
sc
<
<
approx. 1° … 3°





Fig. 8: Mounting the reector when surfaces are reective.
Left: Mounted in driving axis; right: Mounted in lifting axis
1 Distance measuring device
2 Reective surface
3 Reector
4 Tilt of approx. 1 to 3 degrees
