Module parameters
Name Description
Distance
resolution
Determines the resolution of the distance value on the
PROFINET interface; 1 digit can be 0.1 mm, 0.125 mm, 1 mm,
10 mm or 100 mm.
Value range
• 0.1 mm
• 0.125 mm
• 1 mm
• 10 mm
• 100 mm
• free Distance Resolution [µm]
Default value
• 0.1 mm
Free distance
resolution
Determines the resolution of the distance value on the
PROFINET interface if the “free Distance Resolution [µm]”
value has been selected in the “Resolution” parameter.
Value range
• 1 ... 100,000 µm
Default value
• 100 µm
Speed
resolution
Determines the resolution of the speed value on the PROFINET
interface; 1 digit can be 0.1 mm/s,1 mm/s, 10 mm/s or
100 mm.
Value range
• 0.1 mm/s
• 1 mm/s
• 10 mm/s
• 100 mm/s
• free Speed Resolution [µm/s]
Default value
• 1 mm/s
Free speed
resolution
Determines the resolution of the speed value on the PROFINET
interface if the “free Speed Resolution [µm/s]” value has been
selected in the “Resolution” parameter.
Value range
• 1 ... 100,000 µm/s
Default value
• 1,000 µm/s
10.3.8 Module 10: “Status/i2b, Control/o2b”
Type Input and output module, 2 bytes
Description This module reads the device status bytes and writes the control bytes into
the device.
