SICK DL100 Pro

PROFINET IO interface
78 © SICK AG • Subject to change without notice • 8024484/2019-06-06
Example
13-Temp/i1b, Level/i2b, Hrs/i2b
Module 13 consists of three values:
• Temp/i1b
Input value to the master consisting of 1 byte with the “Temp” (tempera-
ture) designation
• Level/i2b
Input value to the master consisting of 2 bytes with the “Level” designa-
tion
• Hrs/i2b
Input value to the master consisting of 2 bytes with the “Hrs” (operating
hour counter) designation
Nomenclature • A byte is an 8-bit value.
• A word is a 16-bit value.
• Consistency means that all values within a module are updated simulta-
neously.
• An input value is transmitted cyclically from the device to the master
(PLC).
• An output value is transmitted cyclically from the master (PLC) to the
device.
• Acongurationvalueistransferredfromthemastertothedeviceevery
time the device is connected. For example, when switching on the
PROFINET IO device or the master or after the connection has been
interrupted.
Relativeaddressspecication Therelativeaddressesarespeciedinthefollowingform:
• <OsetinByte>
• <OsetinByte>.<Bitpositionwithintheinput>or
• <OsetinByte>.<Startbitposition...Endbitpositionwithinaninput>.
10.2.2 Module overview
“01_measured values” module category
Module number Total size Module type Contents
Designation Type Size
1 2 words Input module Distance Input 2 words
2 1 word Input module Distance Input 1 word
3 2 words Input module Speed Input 2 words
4 4 words Input module Distance Input 2 words
Speed Input 2 words
5 2 words Input and out-
put module
Distance Input 2 words
Preset dynamic Output Bit 0 ... 29
Delete preset Output Bit 30
Activating preset Output Bit 31
