SICK DL100 Pro User Manual

PROFINET IO interface
100 © SICK AG • Subject to change without notice • 8024484/2019-06-06
10.3.11 Module 22: “Setup Preset Static”
Type Congurationmodule,noinputandoutputdata
Description This module is used for presetting the static preset value.
Notes If module 5 is also active, the preset value is immediately overwritten by
the input data of module 5.
Module parameters
Name Description
Distance Preset
Static [mm]
Denethedistancepresetvalue.
Value range
• –300,000 ... 300,000
Default value
• 0
10.3.12 Module23:“SetupOset”
Type Congurationmodule,noinputandoutputdata
Description Thismoduleisusedforsettingtheinitialoset.
Notes Ifmodule5isalsoactive,theosetvalueisoverwrittenbyacalculated
osetifaresetfunctionistriggered.Thesameappliesforaswitching
process by MF1.
Module parameters
Name Description
DistanceOset
[mm]
Denetheinitialdistanceosetvalue.
Value range
• –600,000 ... 300,000
Default value
• 0
10.3.13 Module 25: „Special Functions”
Type Congurationmodule,noinputandoutputdata
Description Thismodulecanbeusedtoinuencethebehaviorofthemeasurement
algorithm as well as the temperature stability by setting the temperature
threshold for switching on the heater and the frequency mode.

SICK DL100 Pro Specifications

General

Output	Analog
Operating Temperature	-10 °C to +50 °C
Light source	Laser
Output type	Analog
Supply voltage	10 V DC to 30 V DC
Housing material	Plastic
Connection type	M12 connector
Power consumption	≤ 3 W
