SICK DL100 Pro

Operating the measuring device
52 © SICK AG • Subject to change without notice • 8024484/2019-06-06
8.5.10 “MF1 – Speed” submenu
InthissubmenuyoucanconguretheMF1multifunctionaloutputasa
speed output.
The “Speed” sub-menu is accessed via the following menu path:
Main menu →
→ Menu → →Pron→ → more → →
MFx On → → MF1 → → ActSta → → Functn → → Speed
Requirements for display
• “more” menu: “Yes” option
• “MFx On” menu: “Enable” option
• “Functn” parameter: “Speed” option
Parameters Description
Limit Sets speed switching threshold. The digital output is activated
when the actual speed exceeds the set speed. The switching
hysteresisisxedat±0.1m/s.
Adjustment range
0.0–9.9 m/s
Factory setting
• 0 [mm]
Sign Select the direction of motion to be monitored
Options
• +/–:Ifthesetspeedinaspecicdirectionisexceeded,the
digital output is activated.
• +: If the set speed is exceeded with increasing distance, the
digital output is activated.
• –: If the set speed is exceeded with decreasing distance, the
digital output is activated.
Factory setting
• + / –
Table 19: “MF1 – Speed” submenu
