SICK DL100 Pro

Operating the measuring device
50 © SICK AG • Subject to change without notice • 8024484/2019-06-06
8.5.8 “MF1” menu
InthismenuanditssubmenusyoucanconguretheMF1multifunctional
input/output.
The “MF1” menu is accessed via the following menu path:
Main menu →
→ Menu → →Pron→ → more → →
MFx On → → MF1
Press the
pushbutton to display the “ActSta” parameter.
You can scroll within the menu using the
and pushbuttons. Press
the pushbutton to display the relevant parameter value.
Requirement for display
• “more” menu: “Yes” option
• “MFx On” menu: “Enable” option
Parameters Description
ActSta Select the level or signal edge of the MF1 multifunctional
input/output.
Options
• ActLow: LOW level with active output (NC – normally closed)
or activation of input at falling signal edge
• ActHi: HIGH level with active output (NO – normally open) or
activation of input at rising signal edge
Factory setting
• ActLow
Functn Select function for multifunctional input/output. The corre-
sponding submenu for the chosen function is displayed.
Options
• Dist: MF1 is used as a distance switch output.
• Speed: MF1 is used as a speed switch output.
• Srvice: MF1 is used as a service output.
• LsrO:MF1isusedasaninputforswitchingothelaser.
• Preset: MF1 is used as an input for activating the preset
(overwritingtheoset).
Oset=presetvalue–currentmeasuredvalue
Factory setting
• Dist
Dist/Speed
Srvice/LsrO/
Preset
The corresponding submenu is displayed depending on the
function selected for the “Functn” parameter. See the relevant
table for the parameter description.
Nofurthersubmenuisdisplayedforthe“LsrO”option.Ifthe
MF1multifunctionalinputisactive,thelaserisswitchedo.
Count Counts the switching events of the multifunctional input/out-
put.
You can reset the counter by switching the distance measuring
deviceoandonagain.
Table 17: “MF1” menu
