PROFINET IO interface
Module number Total size Module type Contents
Designation Type Size
6 6 words Input module Time stamp Input 4 words
Distance Input 2 words
7 8 words Input module Time stamp Input 4 words
Distance Input 2 words
Speed Input 2 words
Table 57: Module overview – “01_measured values”
“02_device status” module category
Module number Total size Module type Contents
Designation Type Size
10 2 bytes Input and out-
put module
Status Input 16 bit
Control(LaserO) Output 16 bit
13 5 bytes Input module Temperature [°C] Input 1 byte
Signal level [dB] Input 2 bytes
Service hours [10 h] Input 2 bytes
Table 58: Module overview – “02_device status”
