8024484/2019-06-06 • © SICK AG • Subject to change without notice 91
PROFINET IO interface
Notes Iftherewasnovalidmeasuredvalueduetoadevicefault,amissingreec-
tor or contamination, then the value “0” is output for the distance and the
speed and the corresponding bits are set in the status bytes.
Input values
Rel. Adr. Description
0 Time stamp for the time of measured value recording.
Type
Time stamp, 32 bit seconds
4 Time stamp for the time of measured value recording.
Type
Time stamp, 32 bit split second (1/2
32
)
Input values
(continued)
Rel. Adr. Description
8 Currentdistanceinselectedresolutionwithregardtotheo-
set. Depending on the selected resolution, a digit corresponds
to 0.1 mm to 100 mm.
Type
Signed 32-bit number in two´s complement
12 Currentspeedinselectedresolutionwithregardtotheoset.
Depending on the selected resolution, a digit corresponds to
0.1 mm/s to 100 mm/s.
Type
Signed 32-bit number in two´s complement
