Operating Instructions Chapter 8
Flexi Classic Gateways
8011834/YT28/2016-03-15 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
81
Subject to change without notice
Ethernet TCP/IP Gateway
Get Data Set(s)
The request message is sent by an application to the UE410-EN. The request message
t
elegram shall be structured as shown below:
Parameter Length Value
Command WORD 00F1hex = Data set(s) request message
Request data
set 1
WORD 0 = Do not send data set 1
1 = Send data set 1
Request data
set 2
WORD 0 = Do not send data set 2
1 = Send data set 2
Request data
set 3
WORD 0 = Do not send data set 3
1 = Send data set 3
Request data
set 4
WORD 0 = Do not send data set 4
1 = Send data set 4
Request data
set 5
WORD 0 = Do not send data set 5
1 = Send data set 5
Request data
set 6
WORD 0 = Do not send data set 6
1 = Send data set 6
Sequential
number
WORD Message sequential number — To be returned with the response
The response message is returned to the application by the UE410-EN. The response
message telegram will be structured as shown below:
Parameter Length Value
Command WORD 00F1hex = Data set(s) request message
Data set 1
length
WORD 0 = Do not send data set 1
1 = Send data set 1
Data set 2
length
WORD 0 = Data set not returned in data set(s) data field.
Non-zero = Length of data set
Data set 3
length
WORD 0 = Data set not returned in data set(s) data field.
Non-zero = Length of data set
Data set 4
length
WORD 0 = Data set not returned in data set(s) data field.
Non-zero = Length of data set
Data set 5
length
WORD 0 = Data set not returned in data set(s) data field.
Non-zero = Length of data set
Data set 6
length
WORD 0 = Data set not returned in data set(s) data field.
Non-zero = Length of data set
Sequential
number
WORD Response sequential number
Data set(s) data Array of
Bytes
Data set(s) information
Tab.
78
:
Get Data Set(s)
request
Tab.
79
:
Get Data Set(s)
response
