Technical data
FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH 159
Inputs and outputs
Analog auxiliary voltage
supply
Up to two auxiliary voltages per analog module
Variant-dependent galvanically isolated (  p. 114, §6.5.7)
Output voltage: Approx. 24 VDC, ± 5%
Max. output voltage: 60 mA
Short-circuit proof, through active current limitation > 60 mA
Analog outputs Up to 6 outputs when using I/O modules (option)
4 … 20 mA
According to NAMUR NE43, configurable fault current: high 21 mA and low 3.6 mA
Terminal voltage: 7 … 30 V DC
Precision: ± 0.07% of fullscale @ 23°C
Temperature drift: 7 ppm/K @ 23°C
Resolution: 16 bits
Reverse polarity protection
Galvanically isolated
Passive
Internal update rate 2 Hz
Analog inputs Up to 6 outputs when using I/O modules (option)
Configurable as voltage or current input
24 bits
Reverse polarity protection
The analog inputs per module and the second auxiliary voltage (→ Table 11 - 24V_2/GND_2)
are referred to a ground, they are galvanically isolated from the rest of the circuit.
Internally supplied
Internal update rate 2 Hz
Current measurement:
4 ... 20 mA, according to NAMUR NE43
With error evaluation for < 3.6 (low error) and > 21 mA (high error)
Precision:
± 0.07% of fullscale @ 23°C
Temperature drift: 7 ppm/K @ 23°C
Input impedance: 290 Ω
Single-ended voltage input:
0 … 5 V DC
Precision: ± 0.002% of fullscale @ 23°C
Temperature drift: 45 ppm/K @ 23°C
Input impedance: > 100 kΩ
