16 FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH
System description
3. 1
System components
The FLOWSIC100 Flare-XT measuring system comprises the components:
FLSE100-XT sender/receiver unit (details

p. 27, §5)
For transmitting and receiving ultrasonic pulses, signal processing and controlling the
system functions
Control unit Interface Unit (details

p. 85, §6)
For control, evaluation and output of the sensor data connected via the RS485 inter-
face
Installation accessories (e.g., nozzle, nozzle installation tool, ball valve)
Connection cable between sender/receiver units
Connection cable between sender/receiver units and Interface Unit
Spool piece option
Spool piece preassembled for installation in an existing pipeline (flange connection or
welded connection) including assembly means for installing the sender/receiver units.
External temperature and pressure transmitters available on request
Measuring systems with spool piece option additionally available as:
Dry calibrated (high precision measured system, geometric
uncertainties are minimized.)
Flow calibrated (the complete measuring system has been calibrated on
a flow test bench.)
Both variants reduce measurement uncertainty.
