SICK FLOWSIC100 Flare-XT - Operation in Potentially Explosive Atmospheres

Installation FLSE100-XT
FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH 31
5.2.6
Operation in potentially explosive atmospheres
Depending on the respective device version, the FLSE100-XT sender/receiver units are
designed for use in potentially explosive atmospheres:
Table 1 Device versions
Version Approval
IECEX ATEX NEC/CEC (USA/CA)
F1F-S Ex db [ia Ga] IIA T4 Ga/Gb
Ex db [la Ga] IIB T4 Ga/Gb
Ex db [ia Ga] IIC T6/T4 Ga/Gb
Ex ia IIC T6/T4 Ga
II 1/2G Ex db [ia Ga] IIA T4 Ga/Gb
II 1/2G Ex db [la Ga] IIB T4 Ga/Gb
II 1/2G Ex db [ia Ga] IIC T6/T4 Ga/Gb
II 1G Ex ia IIC T6/T4 Ga
Class I, Division 1, Group D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIA, T4;
Class I, Division 2, Group D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIA, T4
Class I, Division 1, Groups C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB, T4;
Class I, Division 2, Groups C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIB, T4
Class I, Division 1, Groups B, C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB + H2, T4;
Class I, Division 2, Groups A, B, C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIC, T4
F1F-M Ex db [ia Ga] IIA T4 Ga/Gb
Ex db [la Ga] IIB T4 Ga/Gb
Ex db [ia Ga] IIC T6/T4 Ga/Gb
Ex ia IIC T6/T4 Ga
II 1/2G Ex db [ia Ga] IIA T4 Ga/Gb
II 1/2G Ex db [la Ga] IIB T4 Ga/Gb
II 1/2G Ex db [ia Ga] IIC T6/T4 Ga/Gb
II 1G Ex ia IIC T6/T4 Ga
Class I, Division 1, Group D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIA, T4;
Class I, Division 2, Group D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIA, T4
Class I, Division 1, Groups C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB, T4;
Class I, Division 2, Groups C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIB, T4
Class I, Division 1, Groups B, C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB + H2, T4;
Class I, Division 2, Groups A, B, C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIC, T4
F1F-H Ex db IIC T6/T4 Gb II 2G Ex db IIC T6/T4 Gb Class I, Division 1, Groups B, C and D, T4;
Class I, Zone 1, Ex/AEx d IIB + H2, T4;
Class I, Division 2, Groups A, B, C and D, T4;
Class I, Zone 2, Ex/AEx nA IIC, T4
F1F-P Ex db [ia Ga] IIA T4 Ga/Gb
Ex db [ia Ga] IIB T4 Ga/Gb
Ex db [ia Ga] IIC T6/T4 Ga/Gb
II 1/2G Ex db [ia Ga] IIA T4 Ga/Gb
II 1/2G Ex db [ia Ga] IIB T4 Ga/Gb
II 1/2G Ex db [ia Ga] IIC T6/T4 Ga/Gb
Class I, Division 1, Group D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIA, T4;
Class I, Division 2, Group D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIA, T4
Class I, Division 1, Groups C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB, T4;
Class I, Division 2, Groups C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIB, T4
Class I, Division 1, Groups B, C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB + H2, T4;
Class I, Division 2, Groups A, B, C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIC, T4
