Commissioning FLOWSIC100 Flare-XT
FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH 127
7.5.5
Pressure/temperature sensor
▸ Select source of pressure and temperature measured values.
Table 13 Settings for connected pressure or temperature sensors
Selection Parameter Description
pT sensor settings
Single/dual source
Single One sensor connected
Dual
Two sensors connected; an average is
created from both measured sensor values
Fall back type
Last good value
Last valid measured value of connected
sensor
Fixed value Value set under “Fixed value”
Fixed value Entry field
Fixed value for pressure or temperature
If “Fixed value” was selected under “Source
selection” or when a sensor fails.
pT transmitter A/B
Source selection
External live value
Measured value read in via the Modbus
register
Analog input Pressure value read in via an analog input.
Analog input channel
Assignment via which analog input the
measured value is read in
Fixed value Value set under “Fixed value”
P Absolute/Gauge
P Source Abs Gauge
Absolute
The connected sensor is an absolute
pressure sensor
Gauge
The connected sensor is a gauge pressure
sensor
