5.6.8.3
Installing the sender/receiver units
1 Make sure the ball valves are closed.
– If applicable, close ball valves.
– If applicable, remove blind flanges.
2 Position the flange gasket.
3 Position the sender/receiver unit on the ball valve.
Make sure the gasket does not move during positioning.
For cross-duct versions, make sure to install the Slave sender/receiver unit (→ Fig. 10)
on the nozzle on the downstream side so that the sender/receiver unit points against
the flow direction.
4 Insert the 4 bolts with the centering sleeves (→ Fig. 31) and screw the sender/receiver
unit onto the ball valve.
Apply a tightening torque according to the installed gasket,  p. 185, §15.4.
5 Completely loosen the pipe screw fitting.
6 Open the ball valve.
7 Push the sender/receiver unit into the pipeline.
8 Check the gasket of the pipe screw fitting for damage.
9 Screw in the pipe screw fitting and tighten with a torque of 150 Nm.
10 Push the sender/receiver unit to the stop.
11 On probe version F1F-P, now align the measuring path correctly before securing the self-
cutting ring fitting. For cross-duct versions, proceed with the next step.
12 Tighten the self-cutting ring fitting tight 1.25 turns.
Make sure the markings for the self-cutting ring fitting are next to each other again,
→ Fig. 35.
13 For cross-duct versions, install the Master sender/receiver unit on the nozzle on the
upstream side so that the sender/receiver unit points in the flow direction.
Observe when aligning the probe version
Before securing the self-cutting ring fitting again, align probe version F1F-P correctly:
The measuring path must be aligned in flow direction, i.e. the arrow shown must point in
flow direction.
WARNING: Danger due to gas leaks
When gas escapes, close the ball valve again and contact SICK Service.
WARNING: Leakage hazard
Repeated use may damage the gasket of the pipe screw fitting.
▸ Before reuse, i.e. whenever the pipe screw fitting is to be tightened again,
check the gasket of the pipe screw fitting:
▸ Replace the gasket if it has visible deformations, indentations or damage. In
this case contact SICK Service.
Otherwise there is a risk of leakage.
