92 FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH
Installation Interface Unit
6.3.3
Device components
Fig. 48 Overview
1 Type plate 7 Enclosure base
2 Display 8 Pressure compensation element
3 Infrared interface 9 Exterior ground terminal
4 Display cover 10 Cable inlets
5 Screw-on tabs 11 Enclosure door
6 Electronics cover
4
2
1
3
5
5
7
8
9
11 10
6
