SICK FLOWSIC100 Flare-XT User Manual

Installation Interface Unit
FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH 93
Fig. 49 Metric cable glands (optionally available with 9 cable glands)
Fig. 50 Sealing plugs NPT (optionally available with 9 cable entries)
1 Metric cable gland M20
2 Metric cable gland M25
3 Exterior ground terminal
1 12
1
1
1
3
3
1
1
1
1 12
1 Sealing plugs NPT 1/2"
2 Sealing plugs NPT 3/4"
3 Exterior ground terminal
4 Flange plate
5 Identification plates for thread size
4
5
