Installation Interface Unit
FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH 107
Power supply
● DC version
Max. 30 VDC, max. 1 A, recommended cable cross-section: 1 ... 2.5 mm
2
● AC version
Max. 253 VDC, max. 0.5 A, recommended cable cross-section: 0.75 ... 2.5 mm
2
Switching outputs
Max. 30 VDC, max. 70 mA, switching frequency max. 50 Hz, recommended cable cross-
section: min. 0.5 mm
2
Digital output
Max. 30 VDC, max. 70 mA, switching frequency max. 10 kHz, recommended cable cross-
section: min. 0.5 mm2, twisted pair, shielded
Analog output
Max. 30 VDC, max. 24 mA, recommended cable cross-section: min. 0.5 mm
2
, twisted pair,
shielded
Analog input
Max. 30 VDC, max. 24 mA, recommended cable cross-section: min. 0.5 mm
2
, twisted pair,
shielded
RS485
EIA -485, max. 57.6 kbit/s, termination 150 Ohm switchable, recommended cable cross-
section: min. 0.5 mm
2
. twisted pair, shielded
Ethernet
10/100 Mbit/s, protocol Modbus TCP, recommended cable cross-section: Cat 5 or higher
6.5.3 Cable glands
Depending on the variant, the inputs of the device are installed with certified cable glands
or with certified sealing plugs. Use only installation material approved for the hazard zone
involved. The user is responsible for correct selection.
