SICK FLOWSIC100 Flare-XT - F1 F-M; F1 F-H

156 FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH
Technical data
12.2.2
F1F-M
12.2.3 F1F-H
Table 25 Technical data F1F-M
Measuring conditions
Operating pressure:
1)
CL150 device flange: 20 bar (g)
PN25 device flange (optional): 20 bar (g)
CL300 device flange (optional). 20 bar (g)
Gas temperature –196 °C ... +280 °C
Ex approvals
IECEx Ex db [ia Ga] IIA T4 Ga/Gb
Ex db [la Ga] IIB T4 Ga/Gb
Ex db [ia Ga] IIC T6/T4 Ga/Gb
Ex ia IIC T6/T4 Ga
ATEX II 1/2G Ex db [ia Ga] IIA T4 Ga/Gb
II 1/2G Ex db [la Ga] IIB T4 Ga/Gb
II 1/2G Ex db [ia Ga] IIC T6/T4 Ga/Gb
II 1G Ex ia IIC T6/T4 Ga
NEC/CEC (US/CA) Class I, Division 1, Group D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIA, T4;
Class I, Division 2, Group D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIA, T4
Class I, Division 1, Groups C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB, T4;
Class I, Division 2, Groups C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIB, T4
Class I, Division 1, Groups B, C and D, T4;
Class I, Zone 1, Ex/AEx d[ia] IIB + H2, T4;
Class I, Division 2, Groups A, B, C and D, T4;
Class I, Zone 2, Ex/AEx nA[ia] IIC, T4
Installation
Weight ≤ 12 kg (sensor pair)
1)
Temperature-dependent, for details see  p. 165, §12.7  »Derating pressure resistance«
Table 26 Technical data F1F-H
Measuring conditions
Operating pressure:
1)
CL150 device flange:
ATEX/IECEx: 20 bar(g)
CSA: 16 bar(g)
PN25 device flange (optional):
ATEX/IECEx: 20 bar(g)
CSA: 16 bar(g)
CL300 device flange (optional):
ATEX/IECEx: 20 bar(g)
CSA: 16 bar(g)
Gas temperature –70 °C ... +280 °C
Ex approvals
IECEx Ex db IIC T6/T4 Gb
ATEX II 2G Ex db IIC T6/T4 Gb
NEC/CEC (US/CA) Class I, Division 1, Groups B, C and D, T4;
Class I, Zone 1, Ex/AEx d IIB + H2, T4;
Class I, Division 2, Groups A, B, C and D, T4;
Class I, Zone 2, Ex/AEx nA IIC, T4
Installation
Weight ≤ 14 kg (sensor pair)
1)
Temperature-dependent, for details see  p. 165, §12.7  »Derating pressure resistance«
