26 FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH
Project planning
4. 3
Determining the installation location of the Interface Unit
4.3.1 Installation location requirements
▸ Fit the Interface Unit in an easily accessible and protected position.
▸ Observe the information in  p. 96, §6.4.
Providing suitable cables are used, the Interface Unit can be installed up to 1000 meters
from the sender/receiver units. The installation of a flameproof version of the interface unit
directly on site is therefore unnecessary in many situations. For easier access to the
Interface Unit, we recommend installation in a control room (measuring station or similar).
This considerably simplifies communication with the FLOWSIC100 Flare-XT for
configuration or location of failure or error causes.
4.3.2 Clearance for fitting the Interface Unit
NOTICE:
The Interface Unit is only suitable for vertical installation.
NOTICE:
Observe the dimension drawings in  p. 169, §12.8.2.
