160 FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH
Technical data
Digital outputs Switching output
Optionally configurable as digital input
2 per module, up to 6 available when using I/O modules
Galvanically isolated
Max. current: 70 mA
Max. switching frequency: 50 Hz
Max. input voltage: 30 V DC
Switchable Namur/Open Collector
Reverse polarity protection
In Open Collector configuration: Max. switching voltage: 0.5 V DC
In Namur configuration at 8.2 V Us supply voltage:
Power switch state “On”: 4.2 mA
Power switch state “Off”: 0.5 mA
Digital output/frequency output:
4 per module, up to 12 available when using I/O modules
thereof 3 as frequency output
Galvanically isolated
Max. current: 50 mA
Max. switching frequency: 10 kHz
Switching frequency: 0 ... 10 kHz
Max. input voltage: 30 V DC
Switchable Namur/Open Collector
Reverse polarity protection
In Open Collector configuration: Max. switching voltage: 1.8 V DC
In Namur configuration at 8.2 V Us supply voltage:
Power switch state “On”: 3.7 mA
Power switch state “Off”: 0.7 mA
Digital inputs 2 per module, up to 6 available when using I/O modules
Optionally configurable as digital output (switching output)
Galvanically isolated
For connection of potential-free contacts or active switching outputs
Min. switch-on threshold 2 V DC
Max. switch-off threshold 2.85 V DC
Max. terminal voltage: 30 V DC
Reverse polarity protection
Display LCD: Measured variables, system information, warnings, maintenance requests, alarms
Operation Software FLOWgate ™ or control panel at LCD
Installation
Dimensions (W x H x D) See dimension drawings
Weight Non-Ex / zone 2: 8 kg
Weatherproof cover: 8.75 kg
Electrical connection
Operating voltage
AC version DC version
Power supply (nominal) 115 ... 230 V AC ± 10% 12 ... 24 V DC -10/+20%
For installation in system with FLSE100-XT:
15 ... 28 V DC
Frequency 50 ... 60 Hz -
Power 0.33 A
A higher switch-on current must be expected
1 A
A higher switch-on current must be expected
Power input ≤ 18 W ≤ 12 W
Output supply voltage - 24V-OUT (to supply external sensors)
