4.3.2.5 Volume conversion (only for device option volume conversion)
For a detailed description of the single parameters, see the FLOWSIC500 menu description,
p. 91, §5.2.6.5.
▸ Determine the reference values.
▸ Enter the specifications for gas characteristics.
▸ Select the algorithm and parameters for calculating the compressibility factor.
▸ Enter fixed values.
4.3.2.6 Totalizers
Totalizers
▸ Setting or resetting the totalizer levels.
▸ Determine the limits for the reverse flow volume.
Meter settings
▸ Configure the significant digits for the meters:
All meters have up to 9 significant digits, without sign. The number of significant digits
can be varied between 5 to 9.
▸ Determine the resolution for the meters:
The totalizer resolution can be set in the range 0.001 to 100 in increments of factor 10
for the volume at flowing conditions and the volume at base conditions of the meter. It is
therefore necessary to multiply the totalizer level with the corresponding totalizer
resolution to interpret the totalizer level.
4.3.2.7 Completion
▸ If desired, empty the logbooks and archive:
– Activate the checkbox of the logbooks or archive to be emptied.
– Click “Clear selected”.
▸ Check the collection status. If desired, reset the Event overview.
▸ Create a Parameter report:
– Click “Create Parameter report”. The report is generated.
– File the report with the device documentation.
NOTICE:
The totalizer levels are stored in the unit system set in the device. The unit and
resolution are stored in the data records so that the logbooks remain constant
when these settings are changed and need not be reset.
All totalizer levels are deleted when the unit or totalizer resolution are changed.
