SICK FLOWSIC500 User Manual

Operation
FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH 83
Subject to change without notice
Menu navigation (without device option volume conversion)
Some menu functions are only available when you are logged in with user level “User” or
“Authorized User”:
User level: G Guest (standard) U User (1)
User (2)
User (3)
A1
A2
A3
Authorized user (1)
Authorized user (2)
Authorized user (3)
Access rights: - Hidden ○ View ● Start/edit
Path G U A2+3 A1 Explanation
Main display: Volume under measurement conditions V ○ ○ ○ ○
FLOWSIC500 menu: User ○ ○ ○ ○
Logged in user level ● ● ● ● → p. 88, §5.2.6.1
Login ● ● ● ●
Logout - ● ● ●
FLOWSIC500 menu: Device mode ○ ○ ○ ○ → p. 89, §5.2.6.2
Calibration mode ○ ○ ● ●
Configuration mode ○ ○ ● ●
FLOWSIC500 menu: Device information ○ ○ ○ ○ → p. 89, §5.2.6.3
Measuring port ○ ○ ○ ○
Serial number ○ ○ ○ ○
Firmware Version ○ ○ ○ ○
Firmware Date ○ ○ ○ ○
Firmware CRC ○ ○ ○ ○
Metrology CRC ○ ○ ○ ○
Min. oper. pressure ○ ○ ○ ○
Max. oper. pressure ○ ○ ○ ○
Meter factor ○ ○ ○ ○
Frequency at Qr [Hz] ○ ○ ○ ○
Meter factor 2 ○ ○ ○ ○
FLOWSIC500 menu: System settings ○ ○ ○ ○ → p. 89, §5.2.6.4
Power supply (1) [%] ○ ○ ● ●
Power supply (2) [%] ○ ○ ● ●
Date ○ ○ ● ●
Time ○ ○ ● ●
Timezone ○ ○ ● ●
Language ○ ● ● ●
Symbols ○ ○ ○ ○
LCD test ○ ● ● ●
FLOWSIC500 menu: Logbooks ○ ○ ○ ○
Event logbook ○ ○ ○ ○
List of stored events - ○ ○ ○
Parameter logbook ○ ○ ○ ○
Metrology logbook ○ ○ ○ ○
Main display: Error volumes errV ○ ○ ● ●
Main display: Volume flow under measurement
conditions/ gas velocity
○ ○ ○ ○
Main display: Current Events ○ ○ ○ ○
List of current events ○ ○ ○ ○
Main display: Event Summary ○ ○ ○ ○
List of stored events ○ ○ ○ ○
Main display: Last Event Reset ○ ○ ● ● → p. 98, §5.2.12
