SICK FLOWSIC500 User Manual

92 FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH
Operation
Subject to change without notice
5.2.6.6 Pressure parameters (only for device option volume conversion)
5.2.6.7 Temperature parameters (only for device option volume conversion)
5.2.6.8 Logbooks
Heating value Gas heating (under reference conditions)
Heating value unit Heating value unit
Select from: Default, MJ/m³, kWh/m³, BTU/ft³
Default = Standard setting according to selected unit system (SI or US),
configured in accordance with the order
The calculation method selected determines the permissible entry limits for
gas proportions as well as pressure and temperature.
p Sensor type Display of configured pressure sensor
p Sensor serial number Pressure sensor serial number expected by the device, preset
p Lower alarm limit Lower alarm limit for pressure sensor
p Upper alarm limit Upper alarm limit for pressure sensor
p Default value Fixed value for measurement pressure [unit acc. to display]
The entry value is used as fixed value for configuration as TZ conversion
and for pressure measurement malfunctions.
p Unit Unit for pressure values, used for entry and display
Select from:
Default, bar, psia, kPa, MPa, kg/cm
2
, psig
Default = Standard setting according to selected unit system (SI or
Imperial), configured in accordance with the order
p Adjust offset Calibration offset for pressure sensor [unit acc. to display]
p Adjust factor Calibration factor for pressure sensor
T Sensor type Display of configured temperature sensor
T Sensor serial number Temperature sensor serial number expected by the device, preset
T Lower alarm limit Lower alarm limit for temperature sensor
T Upper alarm limit Upper alarm limit for temperature sensor
T Default value Fixed value for measurement temperature [unit acc. to display]
The entry value is used as fixed value for malfunctions of temperature
measurement.
T Unit Unit for temperature values, used for entry and display
Select from:
Default, ° C, ° F, K, °R
Default = Standard setting according to selected unit system (SI or
Imperial), configured in accordance with the order
T Adjust offset Calibration offset for temperature sensor [unit acc. to display]
T Adjust factor Calibration factor for temperature sensor
Event logbook Number of entries currently stored/max. number
Pressing ENTER opens the detailed view.
The detailed view shows the event type, a short text and the timestamp.
Parameter logbook Number of entries currently stored/max. number
Metrology logbook Number of entries currently stored/max. number
Gas composition logbook Number of entries currently stored/max. number
