5.2.6.9 Archives (only for device option volume conversion)
Configuration
Measuring period archive
Gas hour Billing hour for the day archive
Entry range: 00:00 ... 23:59
Default: 06:00
Gas day Billing day for month archive
Measuring range: 1 ... 28
Default: 1
Measuring period Defines the period for the billing archive
Select from: 3 min, 5 min,15 min, 30 min, 60 min
Default: 60 min
List of entries
(0 .. 6000)
Entry x: Entry index, timestamp,
Checksum status OK or Invalid
Date/Time Entry timestamp
To start the editor of the search function, press ENTER.
Entry ID Entry ID, identical to the ID in FLOWgate archive
To start the editor of the search function, press ENTER.
Entry status Status as a hex value and verbal "valid/invalid".
Device status Cumulative system status at the time of the end of the measuring period
VbMP Volume at base conditions V
b
counter reading
To start the editor of the search function, press ENTER.
VbMPΔ V
b
counter progress of the measuring period
VbErrMP Error volume at base conditions
err
V
b
VbErrMPΔ
err
V
b
counter progress of the measuring period
VmMP Volume at measurement conditions V
m
counter reading
VmMP∆ V
m
counter progress of the measuring period
VmErrMP Error volume at measurement conditions
err
V
m
counter reading
VmErrMPΔ
err
V
m
counter progress of the measuring period
QbMP↑ Maximum flow rate at base conditions during measuring period
QMP↑ Maximum flow rate at measurement conditions during measuring period
pMP↑
pMP↓
Maximum and
minimum pressure during measuring period
pMPØ
TMPØ
Average pressure and
temperature (flow-weighted)
KMPØ
CMPØ
Average compressibility and
conversion factor (flow-weighted)
SOSMPØ
Flowtime
Average speed of sound,
Flowtime (time with Q > LowFlowCutOff)
