SICK FLOWSIC500 User Manual

94 FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH
Operation
Subject to change without notice
Daily archive
List of entries
(0 .. 600)
Entry y: Entry index, timestamp,
Checksum status OK or Invalid
Date/Time Entry timestamp
To start the editor of the search function, press ENTER.
Entry ID Entry ID, identical to the ID in FLOWgate Archive
To start the editor of the search function, press ENTER.
Entry status Status as a hex value and verbal "valid/invalid".
Device status Cumulative system status at the time of the end of the day
VbDy Volume at base conditions V
b
counter reading
To start the editor of the search function, press ENTER.
VbDyΔ V
b
counter progress of the day (Dy)
VbErrDy Error volume at base conditions
err
V
b
VbErrDyΔ
err
V
b
counter progress of the day
VmDy Volume at measurement conditions V
m
counter reading
VmDy∆ V
m
counter progress of the day
VmErrDy Error volume at measurement conditions
err
V
m
counter reading
VmErrDyΔ
err
V
m
counter progress of the day
QbDy↑ Maximum flow rate at base conditions during day
QbDy↑ Date/Time Timestamp of maximum flow rate at base conditions during day
QbDy↓ Minimum flow rate at base conditions during day
QbDy↓ Date/Time Timestamp of minimum flow rate at base conditions during day
QDy↑ Maximum flow rate at measurement conditions during day
QDy↑ Date/Time Timestamp of maximum flow rate at measurement conditions during day
QDy↓ Minimum flow rate at measurement conditions during day
QDy↓ Date/Time Timestamp of minimum flow rate at measurement conditions during day
pDy↑ Maximum pressure during day
pDy↑ Date/Time Timestamp of maximum pressure during day
pDy↓ Minimum pressure during day
pDy↓ Date/Time Timestamp of minimum pressure during day
pDyØ Average pressure during day (flow-weighted)
TDyØ Average temperature during day
TDy↑ Maximum temperature during day
TDy↑ Date/Time Timestamp of maximum temperature during day
TDy↓ Minimum temperature during day
TDy↓ Date/Time Timestamp of minimum temperature during day
KDyØ
CDyØ
Average compressibility and
conversion factor (flow-weighted) during day
SOSDyØ Average speed of sound during day
