Parameterizing the Mobile Panel
5.15 Functions for service and commissioning
Mobile Panels 2nd Generation
164 Operating Instructions, 09/2018, A5E33876626-AC
The following functions are available in the menu bar of this dialog:
Connection
Saves the selected connection parameters
Exit Close the "Set Connection" dialog
Edit
Find controllers in the subnet of your HMI device
Restore to
Project
Selected
PLC
Overwrite IP address of the selected device with the IP
address from the project.
All Update IP address and device name of the selected
4. Press the "Find Controller" button.
The configured communication connections are listed in the "Connection Name" column.
Under "Type", you will find the corresponding S7-1200 or S7-1500 controller. Select the
controller to which you want to establish the communication connection.
The message "No connection available in ProjectSettings.hsf data." is displayed:
– If no project has been loaded
– If there is no communication connection to an S7-1200/S7-1500 in the project
5. If the IP address is to be changed, select the relevant communication connection.
The corresponding IP address is displayed in the "IP address" field.
6. Enter the required IP address in the "IP address" text box.
7. Select "Save".
The change is saved.
8. Confirm with "OK".
The dialog closes.
9. Restart the HMI device.
The communication connection is configured.
