Scale parameters and functions of the belt scale
8.22 DR 30 Process state
SIWAREX WP241
Manual, 04/2014, A5E33713528A
123
Totalizing fault Set if totalizing is faulty (when changing
BIT 0 r 0 3004.1
Pulse output active
(see Load per pulse
Signal for quantity per pulse BIT 0 r 0 3005.16
Simulation mode
Simulation mode for weight is enabled BIT 0 r 0 3005.14
Simulation mode
Simulation mode for weight is enabled BIT 0 r 0 3005.13
Stop watch is running Set if stop watch has been started by a
command (e.g. calibration command)
BIT 0 r 0 - - 3005.12
Time buffering failed Set if buffering of the time in RTC has
failed. Is deleted following setting of
BIT 0 r 0 - - 3005.11
Operator error at digit.
input
Set in event of sync. error resulting from
command at digital input
BIT 0 r 0 - - 3005.9
Calibrated Module is calibrated (calibration of
weight measurement and speed)
BIT 0 r 0 - - 3005.8
Calibration command
Set if calibration procedure has been
BIT 0 r 0 - - 3005.6
Write-protect switch is enabled
Analog output
Analog output fault BIT 0 r 0 - - 3005.4
Warm-up time is
Warm-up time following power-up is
BIT 0 r 0 - - 3005.3
Startup Restore point startup or restore has
taken place, is deleted again after 5
BIT 0 r 0 - - 3005.2
1000 Group message "Operating error"
BIT 0 r 0 - - 3006.16
1104 Undervoltage BIT 0 r 0 - - 3006.14
