V800 Series High Performance Closed-Loop Vector Inverter User Manual
Product Introduction
5
2. PRODUCTION INTRODUCTION
2.1INVERTER MODEL
2.2 PRODUCT APPEARANCE
Appearance of Category Ⅱ Applicable for：V800-4T0040G/4T0055P ~ V800-4T0300G/4T0370P
Appearance of Category Ⅲ Applicable for:V800-4T0370G/4T0450P ~ V800-4T1320G/4T1600P
Wiring entrace of extension loopr
Plugboard
Fan
Wiring entrace of main loop
Lower cover
Radiator
Upper housing
Operating panel
Function expansion card
Port of operating panel
Expansion loop terminal
Major loop terminal
Port of remote operating panel
Crystal connector position
(remote operation)
Major loop terminal
Control loop terminal
Port of operating panel
Upper cover
Wiring entrace of extension loopr
Wiring entrace of control loop
Plugboard
Wiring entrace of main loop
Lower cover
Lower housing
Upper housing
Operating panel
