Simphoenix V800 Series - 6.2.24 BUILT-IN AUXILIARY TIMER

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
60
6.2.24 BUILT-IN AUXILIARY TIMER
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F5.1.06
Timer 1 (UT1)
operating mode (H)
_ _ _ X: Clock selection
0: 1ms 1: 1Sec. 2: 1min.
3: Timer 1 cycle reaching pulse (effective for
UT2, UT3)
4: Timer 2 cycle reach pulse (only effective for
UT3)
_ _ X _: Start and stop
0: Multifunctional terminal triggering start
(Edge triggering/ Function No. 52~54)
1: StopRun status change triggering (edge
triggering)
2: RunStop status change triggering (edge
triggering)
3: Synchronously started with timer 1
(effective for UT2, UT3)
4: Timer 1cycle reach pulse (effective for UT2,
UT3)
5: Timer 2 cycle reach pulse (effective for
UT3)
_ X _ _: Timer status resetting (timer value
and status )
0: Multifunctional terminal (Function No.
55~57)
1: Automatic resetting when the cycle is
reached
2: Automatic resetting when timer is stopped
X _ _ _: Timing cycle
0: Single-cycle timing (resetting and
retriggering required)
1: Multi-cycle timing (start again after auto
clearing)
1
0000
×
F5.1.07
Timer 2 (UT2)
operating mode (H)
F5.1.08
Timer 3 (UT3)
operating mode(H)
F5.1.09
Timer 1 timing cycle
0~65535 (clock cycle)
1
30000
F5.1.10
Timer 1 comparative
threshold value
0~[F5.1.09]
1
10000
F5.1.11
Timer 2 timing cycle
0~65535 (clock cycle)
1
30000
F5.1.12
Timer 2 comparative
threshold value
0~[F5.1.11]
1
10000
F5.1.13
Timer 3 timing cycle
0~65535 (clock cycle)
1
30000
F5.1.14
Timer 3 comparative
threshold value
0~[F5.1.13]
1
10000
