Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
79
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
_ X _ _: Coupling command (slave
device parameter)
0: Independent control of slave
device(start and stop not linked)
1: Start and stop command linked
2: Start-stop/jog linked
3: Start-stop/jog/excitation linked
4: Start-stop/jog/excitation/DC bind-type
brake/DC braking linked
X _ _ _: linkage set choice
0: Unit digit of the parameter confirm
1: The input of external terminal
(function No.39)
FA.2.26
Linkage setting
proportion coefficient
0.010~10.000
0.001
1.000
FA.2.27
Fine adjustment source
for linkage proportion
coefficient
0: No fine adjustment
1: Analog inputAI1
2: Analog inputAI2
3: Analog inputAI3
1
0
FA.2.28
Slave device offset
frequency/ Revolution
0: No offset
1: Determined by frequency setting
source 1
2: Determined by frequency setting
source 2
1
0
FA.2.29
Linkage balancing
function
0: Void
1: Current balancing
2: Torque balancing
3: Power balancing
4: Position synchronous balancing
1
0
FA.2.30
Linkage balancing gain
0.001~10.000
0.001
1.000
FA.2.31
Amplitude limiting of
position synchronous
balancing
0.10~10.00Hz
—
1.00
FA.2.32
Reserved
—
—
—
6.2.43 EXPANSION MULTIFUNCTIONAL INPUT TERMINAL
(EDI1~ EDI8)/ Effective after Connecting Expanding Accessories
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.0.00
Expand multifunctional
input terminal EDI1
0~96
1
0
×
Fb.0.01
Expand multifunctional
input terminal EDI2
0~96
1
0
×
Fb.0.02
Expand multifunctional
input terminal EDI3
0~96
1
0
×
Fb.0.03
Expand multifunctional
input terminal EDI4
0~96
1
0
×
Fb.0.04
Expand multifunctional
0~96
1
0
×
