Simphoenix V800 Series - 6.2.8 V;F PARAMETERS AND OVERLOAD PROTECTION (MOTOR 1); 6.2.9 V;F PARAMETERS AND OVERLOAD PROTECTION (MOTOR 2)

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
49
6.2.8 V/F PARAMETERS AND OVERLOAD PROTECTION (MOTOR 1)
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F1.2.15
Reference frequency of motor 1
5.00~300.00Hz/
50.0~2000.0Hz
0.01
50.00
×
F1.2.16
Reference voltage of motor1
50~500V
1
380/220
F1.2.17
V/F curve selection for motor 1
0: Customized curve
1: 1.2 times squares curve
2: 1.5 times squares curve
3: Second square curve
1
0
×
F1.2.18
Torque increasing voltage for motor1
0.0~20.0%
0.1
☆
F1.2.19
Frequency point 1 of motor 1 V/F
curve
0.0~[F0.1.21]
0.01
0.0
×
F1.2.20
Voltage point 1 of Motor 1
V/F curve
0~500V
0.1
0.0
F1.2.21
Frequency point2 of motor 1 V/F curve
0.0~[F0.1.21]
0.01
0.0
×
F1.2.22
Voltage point 2 of Motor 1 V/F curve
0~500V
0.1
0.0
F1.2.23
Frequency point3 of motor 1 V/F curve
0.0~[F0.1.21]
0.01
0.0
×
F1.2.24
Voltage point 3 of Motor 1 V/F curve
0~500V
0.1
0.0
F1.2.25
Slip frequency compensation for
motor 1
0~150(%)
1
0
6.2.9 V/F PARAMETERS AND OVERLOAD PROTECTION (MOTOR 2)
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F1.3.27
Reference frequency of motor 2
5.00~300.00Hz/
50.0~2000.0Hz
0.01
50.00
×
F1.3.28
Reference voltage of motor 2
50~500V
1
380/220
F1.3.29
V/F curve selection for motor 2
0: Customized curve
1: 1.2 times squares curve
2: 1.5 times squares curve
3: Second square curve
1
0
×
F1.3.30
Torque increasing voltage for motor2
0.0~20.0%
0.1
☆
F1.3.31
Frequency point 1 of motor 2 V/F
curve
0.0~[F0.1.21]
0.01
0.0
×
F1.3.32
Voltage point 1 of Motor 2 V/F curve
0~500V
0.1
0.0
F1.3.33
Frequency point 2 of motor 2 V/F
curve
0.0~[F0.1.21]
0.01
0.0
×
F1.3.34
Voltage point 2 of Motor 2 V/F curve
0~500
0.1
0.0
F1.3.35
Frequency point 3 of motor 2 V/F
curve
0.0~[F0.1.21]
0.01
0.0
×
F1.3.36
Voltage point 3 of Motor 2 V/F curve
0~500V
0.1
0.0
F1.3.37
Slip frequency compensation for
motor 2
0~150(%)
1
0
