Simphoenix V800 Series - 6.2.53 BASIC STATUS PARAMETER

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
88
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
0: Electric operation
1: Power generation operation
X _ _ _: Limit suppression
0: No action
1: Over current suppression action
2: Overvoltage suppressor action
3: under voltage suppression action
dE.0.18
Accumulative startup
running time at the last fault
0~65535
1h
65535
R/I
dE.0.19
Startup running interval
between the last two faults
0~65535
1h
65535
R/I
dE.0.20
Actual output frequency
-300.00~300.00Hz
0.01
0
R/I
6.2.53 BASIC STATUS PARAMETER
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
d0.0.00
Output frequency and direction
(rotor synchronous frequency)
-300.0Hz ~ 300.00Hz
0.01Hz
R
d0.0.01
Motor revolution and direction
-30000~30000rpm
1rpm
R
d0.0.02
Output current
0.0~ 6000.0A
0.1A
R
d0.0.03
Output torque
-300.0~300.0%
0.1%
R
d0.0.04
Output voltage
0~500V
1V
R
d0.0.05
Output power
-1000.0~1000.0KW
0.1KW
R
d0.0.06
Device body maximum
temperature
0~150.0°C
0.1°C
R
d0.0.07
Voltage at DC side
0~1000V
1V
R
d0.0.08
Inverter running status
_ _ _ X: Operation mode
0: V/F mode
1: Open-loop vector speed
2: Closed-loop vector speed
3: Open-loop torque control
4: Closed-loop torque control
5: V/F separated control
_ _ X _: Operation status
0: Stop
1: Start acceleration
2: Stop deceleration
3: Decreasing frequency and
deceleration
4: Steady operation
_ X _ _: Electric/ braking
status
0: Electric operation
1: Power generation operation
X _ _ _: Limit suppression
0: No action
1: Over current suppression
1
R
